SkyArc is a Rutile coated general purpose all position quality mild steel electrodes.
It's Features
- Low spatter low smoke
- Normal arc force stable arc
- Easy detachable slag
- Smooth flat to concave,fine rippled bead
- Radiology Quality
ABOUT USABOUT
A RUTILE COATED QUALITY
A RUTILE COATED QUALITY MILD STEEL ELECTRODES
SkyArc is a Rutile coated general purpose all position quality mild steel electrodes.
OUR APPLICATIONS
Generally used for mild steel structures and tanks,truck frames and bodies, ships,pipelines,bridges,etc suitable for joining steels like of astma 283 (P.NO.D & others).
SERVICES OUR SERVICES
A RUTILE COATED
OUR APPLICATIONS
Generally used for mild steel structures and tanks,truck frames and bodies,
ships,pipelines,bridges,etc suitable for joining steels
like of astma 283 (P.NO.D &
others)
| Weld Metal Chemical and Mechanical Properties | Size(mm) | Current Range(Amps) | Packing Data | |||
|---|---|---|---|---|---|---|
| C | 0.10 max | UTS | 410-540 MPa | 2.50 | 60-90 | 135 pes |
| Mn | 0.35-0.60 | YS | 330MPa(min) | 3.15 | 90-125 | 90 pes |
| Si | 0.30 max | EL | 20-28 | 4.0 | 130-170 | 60 pes |
| S | 0.030 max | RA | 50 min | 5.0 | 180-210 | 40 pes |
| P | 0.030 max | CNV at 0C | 47 J(min) | Typical current value: D+ -A50 | ||
OUR RECOMMENDATION
Electrode must be redried at 100 - 110C for 1/2hr.Prior to use.
